Product Description
RSM132-8-660 Monofacial 660W Solar Panel
--132 CELL Mono PERC Module
--640-670Wp Power Output Range
--1500VDC Maximum System Voltage
--21.6% Maximum Efficiency
Key Advantages :
1.Global, Tier 1 bankable brand, with independently certified state-of-the-art automated manufacturing.
2.Industry leading lowest thermal co-efficient of power.
3.Industry leading 12 years product warranty.
4.Excellent PID resistance.
5.Positive power tolerance of 0~+3%.
6.Dual stage 100% EL Inspection warranting defect-free product.
7.Excellent wind load 2400Pa & snow load 5400Pa under certain installation method.
8.Certificates: TUV,CE,IEC,CSA,INMETRO,BIS etc.
Electrical Data (STC):
| Model No.: | RSM132-8-660 | RSM132-8-665 | RSM132-8-670 |
| Rated Power | 660Wp | 665Wp | 670Wp |
| Open circuit voltage-Voc | 45.75V | 45.95V | 46.15V |
| Short circuit current-Isc | 18.33A | 18.38A | 18.43A |
| Maximum power voltage-Vmpp | 38.12V | 38.30V | 38.48V |
| Maximum power current-Impp | 17.32A | 17.37A | 17.42A |
| Module Effiency | 21.2% | 21.4% | 21.6% |
STC: Irradiance 1000 W/m², Cell Temperature 25°C, Air Mass AM1.5 according to EN 60904-3. Bifacial factor: 70%±5 ★ ★ Module Efficiency (%): Round-off to the nearest number.
ELECTRICAL DATA (NMOT):
| Model No.: | RSM132-8-660 | RSM132-8-665 | RSM132-8-670 |
| Maximum Power-Pmax | 500Wp | 503.8Wp | 507.6Wp |
| Open circuit voltage-Voc | 42.55V | 42.73V | 42.92V |
| Short circuit current-Isc | 15.03A | 15.07A | 15.11A |
| Maximum power voltage-Vmmp | 35.38V | 35.54V | 35.71V |
| Maximum power current-Immp | 14.13A | 14.17A | 14.21A |
NMOT: Irradiance at 800 W/m², Ambient Temperature 20°C, Wind Speed 1 m/s.
MECHANICAL DATA:
| Solar Cells | Mono,132cells(6x11+6x11) |
| Size | 2384x1303x35mm |
| Weight | 34KG |
| Frame | Anodized Aluminium Alloy,Type6005-2t6,Silver |
| Cable | 4.0mm2(12AWG),Positive(+)350mm,Negative(-)230mm(MC4 Connector included) |
| Package | 31pcs/pallet(1320x1120x2515mm) |
| Pallet Gross Weigt | 1245KGS |
| 40HQ | 18pallets/558pcs |
